CE Certified Fire Rated Entry Door Manufacturers & Supplier

Engineered for Ultimate Safety, Structural Integrity, and Global Regulatory Compliance. Experience Zhejiang Larsom Door's Industry-Leading Custom Solutions.

Architectural Insights

The Engineering of CE Certified Fire Rated Entry Doors

In modern commercial and high-density residential development, a fire-rated door is not merely an architectural asset—it is a critical, life-saving structural barrier. The CE Certification (EN 16034 / EN 14351-1 standards) establishes that an entry door has undergone rigorous laboratory testing to verify its structural integrity, thermal insulation, and smoke-tightness under extreme heat loads.

Zhejiang Larsom Door Co., Ltd. builds these barriers using a combination of heavy-duty galvanized steel, customized timber variants, mineral cores, and intumescent sealants. These elements combine to prevent the passage of flame and hot gasses for periods of 30, 60, 90, or 120 minutes (EI30 to EI120 classifications), providing vital evacuation pathways and compartmentalizing hazard zones.

Key Safety Parameters

  • Integrity (E): The capacity of the door assembly to withstand fire on one side without transmission of flame or hot gases to the unexposed side.
  • Insulation (I): The ability to restrict temperature rise on the unexposed side, typically keeping it below 140°C above ambient levels.
  • Smoke Control (Sa / S200): Limiting the leakage of cold or hot smoke through the perimeter gaps.
  • Self-Closing (C): Automatic closure using verified overhead closers or spring-loaded hinges during alarms.
Manufacturer Profile

Zhejiang Larsom Door Co., Ltd.

A world-class industrial pioneer specializing in high-security, armored, and fire-resistant entrance configurations.

Larsom Door Headquarter Factory

Advanced Facility & Global Footprint

Since our founding, Larsom Door has maintained a reputation for safety and quality. Operating from a modern production facility covering more than 16,000 square meters in Zhejiang, China, our team of over 160 skilled technicians leverages high-precision manufacturing technologies.

With an established daily output capacity exceeding 200 premium doorsets, we consistently service complex residential, commercial, and hospitality developments globally. We actively export to over 130 countries and regions across Europe, North America, the Middle East, Central Asia, and Africa.

Our engineering capabilities support flexible OEM and ODM partnerships, translating raw design specifications into certified, code-compliant architectural products.

16K+
Sqm Factory Area
160+
Skilled Specialists
200+
Daily Output Sets
130+
Export Destinations
Industrial Technology

Advanced Manufacturing & Supply Chain Advantages

How Zhejiang Larsom Door integrates advanced metallurgy, automation, and localization to deliver cost-effective performance.

Precision Automation

By investing in CNC laser cutters, high-speed turret punching machines, CNC bending machines, and automated welding networks, we guarantee structural tolerances within fractions of a millimeter. This level of precision is essential for fire integrity, ensuring that components align correctly under thermal expansion.

Chinese Supply Chain Value

Located within the Zhejiang industrial corridor, we enjoy direct access to primary steel processing, high-density timber resources, and advanced hardware ecosystems. This vertical alignment lowers raw material transport costs and speeds production lead times, allowing us to offer competitive pricing without sacrificing safety.

Global Standards Alignment

Larsom designs meet various international standards, including BS 476, EN 1634, and UL 10C. We adjust raw material matrices, frame depths, and hardware provisions to match local specifications across European, Middle Eastern, and North American markets.

Factory Operations

Precision Fabrication Process

A step-by-step view of how Zhejiang Larsom Door fabricates high-durability fire-rated doors from raw materials to final finishes.

Pressing Plate
1. Pressing Plate
Splicing
2. Timber Splicing
Edge Sanding
3. Edge Sanding
Engraving
4. Core Engraving
UV Production
5. UV Production Coating
Plate Shearing
6. Metal Plate Shearing
Plate CNC Cutting
7. CNC Sheet Laser Cutting
Plate Bending
8. Precision Hydraulic Bending
Punching
9. Hardware Punching & Mortising

Our facility uses a dedicated assembly process (shown above) to produce both high-security armored exterior doors and laminated timber variants. We monitor each stage, from raw sheeting and core calibration to final curing, to ensure structural consistency.

Zhejiang Larsom Door factory production
Procurement Specs

Compliance & Structural Standards

Technical configurations designed for developers, architects, and quantity surveyors to meet global build codes.

Different jurisdictions require specific standards for commercial and residential fire doors. The table below outlines how Larsom Door matches international specifications:
Standard Code Target Region Common Ratings Required Key Hardware/Core Requirements Larsom Solution Features
EN 1634-1 / EN 13501-2 European Union & Associated Markets EI30, EI60, EI90, EI120 Intumescent seals, mineral wool/calcium silicate cores, CE marked hinges & closers. Fully CE-certified structures, smoke seal integration, European lock-case configurations.
BS 476 Part 22 United Kingdom, Commonwealth, Middle East FD30, FD60, FD90, FD120 Perimeter intumescent strips, solid particleboard or mineral core, certified ironmongery. Timber and steel fire doors matching BS certification; full compatibility with British standard locks.
UL 10B / UL 10C / NFPA 252 North America, Latin America, Middle East 20, 45, 60, 90, 180 Minutes Positive pressure testing, hose stream resistance, listed door frames, and self-latching devices. Armored steel profiles, heavy-gauge steel framing, customized perimeter gaskets for smoke containment.
ISO 9001:2015 Global Quality Standard Corporate Compliance Documented quality checks at all production stages, raw material tracking. Full material batch-tracking and factory output QA reports for every order.
Industry Insight

Trends & Localized Applications

How fire-rated entry doors adapt to modern smart building demands and high-traffic commercial environments.

Smart Lock Integration

Modern developers increasingly require entry doors that combine thermal protection with electronic security. We supply customized mortises compatible with RFID, biometric, and IoT-enabled smart locks. These locks are engineered to release under signal alerts to support emergency egress.

High-Traffic Hospitality

Hotels require acoustic insulation (STC ratings) alongside fire protection. Larsom timber fire doors feature multi-layer acoustic insulation core materials. This design provides both peace of mind during fire events and a quiet guest experience.

Armored Exterior Solutions

For residential entrances exposed to external elements, we supply galvanized steel-wood composite doors. These designs protect against exterior weathering while meeting indoor fire-barrier standards, using materials that resist warping under temperature extremes.

FAQ

Frequently Asked Questions

Expert engineering answers regarding procurement, certification, installation, and custom manufacturing.

Q1. What parameters verify the CE Certification of Larsom's fire rated entry doors?
Our fire doors are evaluated under EN 1634-1 testing standards (determining thermal insulation and integrity) and certified in compliance with EN 16034 (harmonized product standard for fire doorsets). This testing certifies that under exposure to temperatures exceeding 1000°C, the frame and leaf structure prevent flame escape (Integrity 'E') and contain heat radiation (Insulation 'I') for specified durations of 30 to 120 minutes.
Q2. How does Zhejiang Larsom Door support customization requirements for large projects?
We provide full OEM and ODM customization support. Our in-house technical engineers can adapt dimensions, veneer finishes (including MDF, PVC, WPC, and natural wood species), locking mechanisms, and frame depths to match local building regulations. We also offer tailored solutions for security integrations, acoustic ratings, and weatherproof requirements.
Q3. What raw materials form the core of a fire-rated door assembly?
For wood-based fire-rated doors, we construct the assembly around a high-density mineral board (such as calcium silicate) or a particle core treated with fire retardants. For steel and armored door configurations, we use high-grade rock wool or ceramic fiber insulation materials inside heavy-gauge galvanized steel sheets. Additionally, we integrate perimeter intumescent seals that expand to seal frame gaps when exposed to heat.
Q4. What is the standard manufacturing lead time for wholesale or project orders?
Our 16,000 square meter factory produces more than 200 doorsets daily. For standard container-grade orders, our standard production lead time is 25 to 35 days from deposit confirmation and drawing approval. Custom-designed orders requiring specialized raw materials or complex architectural finishes may take slightly longer, which will be detailed during project scoping.
Q5. How do you handle localization and regional code approvals?
Our products are exported to over 130 countries, each with specific testing codes (e.g., BS 476 in the UK and Middle East, UL 10C in the Americas, and EN standards in Europe). We supply the necessary test certificates, material datasheets, and structural drawings required by local inspectors to verify fire safety compliance before installation.
Q6. What options do you offer for smart lock compatibility?
Our production line includes CNC routing and mortising steps. We can prepare the door leaf and frame for a wide range of mortises, including standard mechanical systems, multi-point locking systems, and smart electronic locks (using fingerprint, keypad, or card access). We work with your lock supplier's specifications to ensure proper fitment during production.
